prospero.vm
is a plain-text file containing 7866 math expressions.
It begins as follows:
# Text of a monologue from The Tempest
_0 const 2.95
_1 var-x
_2 const 8.13008
_3 mul _1 _2
_4 add _0 _3If you evaluate the expression with (x,y) values in the ±1
square, then color pixels black or white based on their sign, you get the
following image:
The "challenge" is simple: render the image as quickly as possible.
A basic renderer is 28 lines of Python, using Numpy for pixel parallelism:
import numpy as np
with open('prospero.vm') as f:
text = f.read().strip()
image_size = 1024
space = np.linspace(-1, 1, image_size)
(x, y) = np.meshgrid(space, -space)
v = {}
for line in text.split('\n'):
if line.startswith('#'):
continue
[out, op, *args] = line.split()
match op:
case "var-x": v[out] = x
case "var-y": v[out] = y
case "const": v[out] = float(args[0])
case "add": v[out] = v[args[0]] + v[args[1]]
case "sub": v[out] = v[args[0]] - v[args[1]]
case "mul": v[out] = v[args[0]] * v[args[1]]
case "max": v[out] = np.maximum(v[args[0]], v[args[1]])
case "min": v[out] = np.minimum(v[args[0]], v[args[1]])
case "neg": v[out] = -v[args[0]]
case "square": v[out] = v[args[0]] * v[args[0]]
case "sqrt": v[out] = np.sqrt(v[args[0]])
case _: raise Exception(f"unknown opcode '{op}'")
out = v[out]
with open('out.ppm', 'wb') as f: # write the image out
f.write(f'P5\n{image_size} {image_size}\n255\n'.encode())
f.write(((out < 0) * 255).astype(np.uint8).tobytes())On my machine, this takes about 15 seconds to produce a 1024×1024 image.
(Spoilers: it also allocates 60+ GB of RAM for intermediate results, so consider reducing the image size before running it on your own machine)
"But wait!", you say. "There's so much obvious room for improvement! You
could pre-parse the expression, or use numba, or run it on
the GPU, or use LLVM ..."
Yes. I would like you to do those things, and then tell me about them!
This page has been seeded with a few of my projects, but I'd like for it to grow to contain different experiments by other people.
A few ideas to think about:
(x,y) coordinates. How does your system handle
interactive viewing of the model?
Feel free to submit both successful and unsuccessful experiments via
email to
matt.j.keeter@gmail.com,
and I will add them to this page.
The ideal submission would be a blog post or code repository, along with a few-sentence description that you'd like included on this page. I'd also be happy to include hero images or video embeds.
The description should call out any particularly promising results, clever ideas, or interesting tools! Don't get too fixated on absolute speed; the goal is to explore ideas, and that can absolutely be done without breaking any performance records!
Besides eternal fame and glory?
If you submit an interesting write-up, I will buy you a coffee or drink if we happen to be in the same city. It will be particularly easy for Cambridge / Boston / Somerville residents to receive their prize; I make no guarantees for submissions from farther afield.
Interval Arithmetic and Recursive Subdivision for Implicit Functions and Constructive Solid Geometry (Duff '92) is a great introduction to common techniques. In particular, the combination of interval arithmetic, spatial subdivision, and expression simplification remains the basis for modern renderers.
These ideas are also presented in §3.7 of my thesis, Hierarchical Volumetric Object Representations for Digital Fabrication Workflows (2013), although my personal implementations have evolved since then (see below for examples).
Finally, I gave a talk titled Implicit Surfaces & Independent Research (2025), which covers all of this material and hews closely to my current implementations. The audience was CS undergraduates in their senior year, so it's intended to be approachable!
The MPR implementation compiles the expression down to a register-based bytecode, then executes it with a small interpreter running in a CUDA kernel. The interpreter evaluates the expression using interval arithmetic on many spatial regions in parallel, then simplifies the expression, subdivides the active regions, and recurses. Below a certain size, we swap over to per-pixel evaluation, also in parallel on the GPU.
Expression simplification is particularly important for performance: by the time we evaluate individual pixels, the expression is 200× smaller!
Most of the hard work went into making a deeply recursive algorithm (with heterogeneous workloads in each branch) into something more GPU-friendly.
Rendering a 1024×1024 image takes 3.9 milliseconds using a Tesla V100, which was a high-end GPU back in 2020 (and is still absurdly powerful). Performance is basically flat through 4096×4096, indicating that we're far from saturating the GPU for this kind of 2D rendering (the paper also describes a similar strategy for 3D rendering).
Unfortunately, I don't have timing numbers for setup time, but the kernels are generic interpreters, i.e. not specialized to a particular expression.
Fidget uses the same broad strategy of interval evaluation and expression simplification, but runs on the CPU and compiles expressions down to machine code with a JIT compiler.
Running on an M1 Max CPU (2021), it renders a 1024×1024 image in 6.3 milliseconds, with about 11 ms of setup time:
$ cargo run -pfidget-cli --release -- render2d -i models/prospero.vm \
-s1024 --eval=jit -N500 --mode mono
[2025-03-23T21:26:44Z INFO fidget_cli] Loaded file in 4.994333ms
[2025-03-23T21:26:44Z INFO fidget_cli] Built shape in 6.04525ms
[2025-03-23T21:26:47Z INFO fidget_cli] Rendered 500x at 6.331644 ms/frame
Scaling up to 4096×4096, it takes 57 milliseconds, which is about 9× slower; this is sublinear scaling, because it's 16× more pixels.
There are a few interesting aspects to this project:
Max addresses the "60 GB of intermediate results" issue by adding garbage collection to the Python interpreter, seeing a quick 4× speedup (and a dramatic reduction in RAM usage, down to about 1 GB).
The post also shows off CuPy, a drop-in replacement for Numpy which offloads computation to the GPU. Simply replacing the import statement yields a further 6.6× speedup!
This demo shows the raw power of a modern GPU, rendering a 4096×4096 frame in about 0.5 milliseconds. The expression is translated directly into a CUDA kernel then compiled and run, evaluating all of the pixels in parallel without the overhead of an interpreter loop.
The downside to this approach is significant startup time – about 2 seconds to compile the kernel – which makes it less suitable for interactive design work. Still, for workflows that focus on viewing static expressions, it's hard to beat.
As a side note, Kevin and I are both puzzled by the specific performance
numbers. His GPU has a theoretical max performance of
83
TFLOPS; however, 0.5 milliseconds for 4096×4096 pixels (with 6461
non-const expressions) implies about 200 TFLOPS! If you
have theories about the discrepancy, feel free to reach out.
This writeup optimizes brute-force evaluation with a bunch of interesting tools and techniques:
We went from around 5 seconds to ~270 ms. We started with using cranelift for JIT compilation, added rayon to process pixels in parallel, tried switching to f32, and finally added vectorization to get 4 pixels processed per function invocation. Compared to the original python's 15 seconds, I'd say that's pretty good.
I'm also left with a deeper appreciation for the Cranelift compiler: it's both fast (34 milliseconds to compile the whole expression) and easy to embed (coming in under 200 lines of code).
That's all for now; but you can help by submitting your own experiments!
